Adding a second extruder to your 3D printer can significantly expand its capabilities, enabling you to print with two different materials or colors simultaneously. This process, known as dual extrusion, can be particularly useful for creating complex models with multi-materials (such as support structures) or adding more detail and aesthetics to your prints.
While adding a second extruder may seem complicated, it is entirely possible with some basic technical knowledge, patience, and the right tools. In this guide, we’ll walk you through the steps of adding a second extruder to your 3D printer.
1. Ensure Your Printer is Dual Extruder-Compatible
Why It’s Important:
Not all 3D printers are designed to support dual extruders. Before attempting to add a second extruder, make sure your printer’s hardware and firmware are capable of handling the additional extruder.
How to Check:
- Check the Printer’s Documentation: Some 3D printers come with dual extruder options or kits designed specifically for them. If your printer didn’t come with a second extruder option, check if the manufacturer offers an upgrade or conversion kit.
- Space for Additional Extruder: Ensure that your printer has enough space to fit an additional extruder. Check if there are available mounting points for the extruder and hotend.
- Firmware Support: Verify that the printer’s firmware can support dual extrusion. Some popular 3D printers may need a custom firmware update to support dual extruders, so check if this is available for your printer model.
2. Acquire a Dual Extruder Kit or Components
Why It’s Important:
You’ll need a few specific components to successfully add a second extruder. A dual extrusion kit typically includes the second extruder, a hotend, wiring, and sometimes the necessary hardware for mounting the extruder.
What You’ll Need:
- Dual Extruder Kit: If available, this is the easiest option. Many 3D printers offer official upgrade kits designed specifically for their models, which include everything you need for the second extruder.
- Second Hotend: If your printer uses a modular extruder system, you may need to purchase a second hotend.
- Additional Stepper Motor: Your printer may require a second stepper motor to operate the second extruder.
- Wiring and Connectors: Ensure you have the right wiring and connectors to power the second extruder.
- Mounting Hardware: Depending on your printer’s design, you may need additional screws, brackets, or rails to mount the second extruder properly.
3. Install the Second Extruder on Your Printer
Why It’s Important:
Proper installation of the second extruder is crucial for ensuring smooth operation. Incorrect installation can result in alignment issues, filament jams, or even damage to the printer.
Steps for Installation:
- Remove the Print Head: If necessary, remove the existing print head to make space for the second extruder. This step will vary depending on your printer’s model.
- Mount the Second Extruder: If your printer has a designated spot for a second extruder, attach the extruder bracket securely to the frame. If not, you may need to design or purchase a custom mounting solution. Ensure that the extruder is level with the first one.
- Install the Second Hotend: Attach the second hotend to the extruder bracket, ensuring it’s firmly secured and aligned. If your printer uses a bowden system, attach the second extruder’s bowden tube securely to the hotend.
- Wire the Stepper Motor: Connect the stepper motor for the second extruder to the appropriate port on the printer’s mainboard. Ensure the motor is securely connected to the extruder mechanism and that the wiring is routed neatly to avoid interference with moving parts.
- Connect the Heated Bed Wires (If Needed): Some setups may require an additional heated bed wire for the second extruder. Make sure this connection is secure and properly insulated.
4. Update the Printer’s Firmware
Why It’s Important:
Most 3D printers need firmware updates when adding a second extruder. The firmware tells the printer how to manage the second extruder’s movements, temperature settings, and extrusions.
How to Update:
- Check Firmware Compatibility: Visit the manufacturer’s website to find out if a firmware update is available for dual extrusion. If not, you may need to install custom firmware like Marlin that supports dual extruders.
- Install the Firmware: Using a USB or SD card, upload the new firmware to the printer’s control board. Be sure to follow the installation instructions provided by the firmware source.
- Test Extruder Settings: Once the firmware is installed, check the printer’s control panel for extruder settings. Ensure both extruders are recognized by the firmware and that their temperature settings are accurate.
5. Configure the Slicing Software for Dual Extrusion
Why It’s Important:
Dual extrusion printing requires specialized slicing software settings to ensure both extruders work together effectively, managing their movements and material deposits accurately.
How to Configure:
- Install Dual Extruder Profile: Open your slicing software (e.g., Cura, PrusaSlicer, or Simplify3D) and ensure you have a dual extrusion profile set up for your printer. Many slicing software packages come with preset profiles for common dual-extruder 3D printers.
- Assign Materials to Each Extruder: Configure which material will be fed into each extruder (for example, PLA in the primary extruder and PVA or another filament for supports in the second extruder).
- Print Settings: Set print speeds, layer heights, and extrusion rates for both extruders. Make sure to account for the fact that two extruders are running, so you may need to adjust the print speed or retraction settings.
- Check Support Structure Settings: For dual extrusion, ensure that your software generates the right type of support structure (like dissolvable filament supports if you’re using a second extruder for support material).
6. Perform Test Prints
Why It’s Important:
Before jumping into complex prints, it’s essential to test your new dual extrusion setup with simple prints. This will help you fine-tune the extruders and make sure everything is working properly.
Test Prints to Try:
- Dual Color Prints: Try printing a model with two different colors to ensure that both extruders are working correctly and switching seamlessly.
- Multi-Material Prints: If you’re using two different materials (such as PLA and PVA), ensure that the printer switches between them without any issues, and that the support material is being deposited properly.
- Adjust Retraction Settings: Dual extrusion setups require fine-tuning of retraction settings to prevent oozing or stringing between extruder switches. Adjust these settings in your slicer software based on the test print results.
7. Troubleshoot Potential Issues
Common Problems and Solutions:
- Clogging: Dual extrusion setups are prone to clogs, especially if one extruder is not properly primed or the material is inconsistent. Regularly clean the nozzles and perform cold pulls to prevent blockages.
- Incorrect Layer Alignment: If the layers aren’t lining up properly, check the calibration of both extruders, ensure the bed is level, and that both hotends are at the correct height.
- Oozing or Stringing: Tuning the retraction settings for both extruders is essential to minimize oozing when switching between extruders.
- Material Contamination: Be cautious about filament contamination when switching between extruders, especially with different types of materials like PLA and PVA. Consider purging the extruder with the unused material to avoid cross-contamination.
Conclusion
Adding a second extruder to your 3D printer opens up a world of possibilities, from multi-material prints to multi-color designs and improved support structures. While the process may seem daunting, it is manageable with the right tools, proper setup, and patience.
By following these steps—ensuring compatibility, installing the extruder, updating the firmware, configuring slicing software, and performing test prints—you’ll be on your way to mastering dual extrusion in no time.
